F37 Opening slow-down point 10 = 10% of the travel / … / 25 = 25% of the travel (default) / … / 60
= 60% of the travel
Percentage adjustment of the total gate travel, of the opening slow-down starting point.
 This function appears only is the Encoder function is activated.
F38 Closing slow-down point 10 = 10% of the travel / … / 25 = 25% of the travel (default) / … / 60
= 60% of the travel
Percentage adjustment of the total gate travel, from the closing slow-down starting point.
 This function appears only is the Encoder function is activated.
F49 Manage serial connection 0 = Deactivated (default) / 1 = Paired / 3 = CRP
To enable paired operation or the Came Remote Protocol.
F50 Save data 0 = Deactivated (default) / 1 = Activated
Saving users and saved settings in memory roll.
 This feature only appears if a memory roll has been fi tted into the control board.
F51 Read data 0 = Deactivated (default) / 1 = Activated
Uploading data saved in memory roll.
 This feature only appears if a memory roll has been fi tted into the control board.
F52 Passing parameter in
paired mode
0 = Deactivated (default) / 1 = Activated
Uploading settings from Master to Slave.
 This appears only if function F49 is set to Paired.
F54 Opening direction 0 = Opening towards the left (default) / 1 = Opening towards the right
For setting the gate opening direction.
F56 Peripheral number 1 ----> 255
To set the peripheral's number from 1 to 255 for each control board when you have a system with several
operators.
F63 Change COM speed 0 = 1200 Baud / 1 = 2400 Baud / 2 = 4800 Baud / 3 = 9600 Baud / 4
= 14400 Baud / 5 = 19200 Baud / 6 = 38400 Baud / 7 = 57600 Baud /
8 = 115200 Baud
For setting the communication speed used in the CRP (Came Remote Protocol) connection system.
F65 RIO-EDGE [T1] wireless
input
0 = Deactivated (default) / 7 = P7 / 8 = P8
RIO-EDGE wireless safety device associated to any function chosen among those available: P7 = reopening
during closing, P8 = reclosing during opening.
For programming, see the instructions that come with the accessory.
 This function only appears is the control board has been fi tted with a RIO-CONN card.
F66 RIO-EDGE [T2] wireless
function
0 = Deactivated (default) / 7 = P7 / 8 = P8
RIO-EDGE wireless safety device associated to any function chosen among those available: P7 = reopening
during closing, P8 = reclosing during opening.
For programming, see the instructions that come with the accessory.
 This function only appears is the control board has been fi tted with a RIO-CONN card.
