STYLO-ME
Pag.
4
4 - Manual code:
119DV11
119DV11 ver.
1.0
1.0 03/2010 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Control board power supply: 230 AC 50/60Hz
Motor power supply: 24V DC 50/60Hz
Max draw.: 5A
Power: 48W
Maximum torque: 100Nm
Opening time (90°): adjustable
Gear ratio: 1/531
Duty Cycle: Intensive use
Protection Rating: IP54
Weight: kg
Working temperature:
#
#
This product is designed and built by CAME CANCELLI AUTOMATICI S.p.A. in compliance with current safety norms.
Guaranteed 24 months unless tampered with.
Description
Intended use
Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
Intended use and restrictions
The STYLO-ME gearmotor is designed to automate residential and apartment block swing-gates in even intensive use conditions.
Restrictions
Technical features
Gate-leaf width (m) 0,8 1,2 1,8
Gate-leaf weight (kg) 150 125 100
Intelligent Security & Fire Ltd.
