CAME STYLO Series User Manual

57
650
80
437,5
106
STYLO-BS
STYLO-BD
90°
330
330
STYLO-ME
1
5
3
2
6
4
4
STYLO-BS
STYLO-BD
7
8
9
STYLO-ME
12
10
11
Pag.
5
5 -
Manual code
:
119DV11
119DV11 ver.
1.0
1.0 03/2010
© CAME cancelli automatici s.p.a. -
The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Dimensions
Description of parts
1) Main body of the gearmotor
2) Upper cap
3) Lower cap
4) Hinged arm
5) STYLO-BS arm securing bracket
6) Gearmotor securing bracket
7) STYLO-BS cover
8) STYLO-BD cover
9) Slide guide
10) Opening stop
11) STYLO-BD slide rail
12) Closing stop
(mm)
