Description of parts
1. Cover
2. Gearmotor
3. Transformer
4. Control board
5. Transmission arm for the VER10*
6. Transmission arm for the VER12*
7. Door fastening brace
8. Guide fastening brace
9. Ceiling fastening brace
10. Cable gland
11. Fastening screws
☞(*) Only for sectional doors.
Dimensions
Description of the traction guide
1. Guide
2. Chain or belt
3. Traction assembly with release lever
4. Mechanical stop
5. Support rods
