09/2007 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH


,
.
+
-
Power supply
230V (a.c.) 50/60 Hz
Terminals for powering the following accessories:
- 24V a.c. (normally alternated power)
- 24V a.c. (continuous power) when the emergency batte-
ries are in operation.
Overall power allowed: 37W
6.3 - POWER SUPPLY TO ACCESSORIES
-
.
- .
%.#
%.#
FROG-J / A1824
M2 - 24V d.c. gearmotor
featuring delayed action on closing
6.2 - CONNECTING TO THE GEARMOTORS
FROG-J / A1824
M1 - 24V d.c. gearmotor
featuring delayed action on opening
BLACK
BROWN
BLUE
BLUE
BLACK
BROWN
