Pag.
7
-
Manual code
:
319U16
319U16 ver.
0.
0.
5
09/2007
© CAME cancelli automatici s.p.a. -
The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH


%
0
#8
#9
43
Signal Flasher
(socket rating: 24V - 25W max.)
Flashes during opening and closing phases
Open gate indicator-light
(socket rating: 24V - 3W max.).
Turns on when the gate is ajar or open.
It turns off when the gate is closed.
(Also see Chapt. 6.4)
6.5 - SIGNALLING AND LIGHTING DEVICES
6.4 - ELECTRICAL LOCK
After hooking it up as shown in the illustration,
proceed as follows:
a) - Set dip switch 6 to ON (and dip switch
3 to OFF)
;
;
b) - press CH1: the red PROG led will start to
blink;
c) - when the led stays on (after about 5
seconds) the procedure is complete;
d) - set to the dip switches back to OFF (or
to the previous position, which depends on the
functions selection, see paragraph 7, page 10).
N.B.: to return to default (indicator lamp on 10-5),
follow the same procedure while pressing CH2.
ZL90 allows you to connect, alternatively to the indicator light on 10-5, a 12V (15W max) electrolock, and if necessary also the “Ram
Blow” function.
a)
To activate the “ram blow”
(1)
:
a
a
) - Set
) - Set
dip switches 3 and 6 to ON
dip switches 3 and 6 to ON
;
;
b
b
),
),
c
c
),
),
d
d
) - continue with the above
) - continue with the above
COMMON PROCEDUR
COMMON PROCEDURE.
N.B.: to exclude the ram blow, follow the same procedure while pressing CH2.
(1)
Upon each opening command, the gate leaves press on the closing jamb for one second,
assisting the electrolock release operation.


%
0
#8
#9
43
5
p
l
ace
a 3.15 A
fuse in between
17V
transformer
terminal
a)
b)
COMMON PROCEDURE
d)c)
