Canon 4K500ST User Manual

168
Product Specifications
Displayed Test Patterns
To access the test pattern menu, from the [Install settings] menu, select [Test
pattern] (P107) > [On], or press the TEST PATTERN button on the remote control.
While the test pattern is displayed, you can use the [ ] / [ ] buttons to switch
patterns. Also, if there is an option pattern available, you can use the [ ] / [ ]
buttons to switch pattern.
The following test patterns can be displayed.
Use [ ] / [ ] to
switch patterns
Use [ ] / [ ] to switch
option patterns
Raster 100%
(White / red / green / blue)
Raster 50%
(White / red / green / blue)
Color bars
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
Stairstep H
Stairstep V
Cross Hatch
Border
Focus
Multi
Checker
Color steps
Character
DICOM
