Before Use
26
Side Control
(1) POWER button (P60, P79)
Turns the projector on or off.
(2) INPUT button (P63)
Switches the input signal.
(3) LENS button (P67)
Each time the button is pressed,
the adjustment window changes,
from focus (P67) to zoom (image
size) (P68) to lens shift (image
position) (P70).
To adjust the image, use the [ ] /
[ ] or [ ] / [ ] buttons.
After the focus adjustment window,
the marginal focus adjustment
window is also displayed for
adjusting focus of image edges
(P157), depending on the [Marginal
focus] setting (P102).
(4) KEYSTONE button (P73)
Corrects keystone distortion.
(5) Pointer / VOL buttons (P85)
Up, down, left, or right in menu
navigation or other operations.
Adjust the sound volume.
[ ] VOL– button: Decreases the
volume.
[ ] VOL+ button: Increases the
volume.
(6) OK button (P86)
Determines the item selected from
the menu.
(7) MENU button (P84)
Displays a menu on the screen.
(1)
(2)
(3)
(4)
(6)
(5)
(7)
