Canon imagePRESS 1110 Service Manual

2
2
2-81
2-81
Technology > Fixing System > Servicing work > Action for parts replacement
Technology > Fixing System > Servicing work > Action for parts replacement
Servicing work
■
Periodically Replaced Parts
No. Part name Part No. Q'ty Interval Remarks
1 Fixing roller main thermistor FK2-6479 1 1000K
2 Fixing roller sub thermistor FK2-6478 1 1000K
3 Fixing roller thermo switch FM3-2781 1 1000K
4 Pressure roller main thermistor FK2-6479 1 1000K
5 Pressure roller sub thermistor FM3-2874 1 1000K
6 Pressure roller thermo switch FK2-6478 1 1000K
7 Externl heat roller thermistor FK2-7282 1 1000K
8 External heat roller thermo switch 1 FM3-2778 1 1000K
9 External heat roller thermo switch 2 FM3-2779 1 1000K
■
Durables
No. Part name Part No. Q'ty Interval Remarks
1 Fixing web FC7-8910 1 1000K
2 Fixing web roller FC8-9709 1 5000K
3 Fixing roller
FL2-7345 1 1000K TYPE A
FL2-7437 1 1000K TYPE B
4 Fixing roller insulate bush FL2-7395 1 1000K
5 Fixing roller bearing XG9-0421 1 1000K
6 Pressure roller
FL2-7650 1 1000K TYPE A
FL2-7438 1 1000K TYPE B
8 Pressure roller insulate bush FC8-9693 1 1000K
7 Pressure roller bearing XG9-0477 1 1000K
9 Refresh roller FM3-2876 1 1000K
10 External heat roller unit FM3-2785 1 1000K
Operator replace the unit.
Service engineers replace the
external heat roller, cleaning
roller, insulate bush and bearing.
11 External heat roller FC9-7217 1 1000K
12 External heat cleaning roller FM3-1647 1 1000K
13 External heat insulate bush FC5-2582 1 1000K
14 External heat bearing XG9-0750 1 1000K
15 Fixing roller separation claw FM3-2878 1000K
16
Pressure roller separation claw
unit
FM3-2776 1000K
Operator replace the unit.
Service engineers replace the
lower separation claw.
17 Pressure roller separation claw FM3-2769 1 1000K
T-2-76
T-2-77
■
Periodial Servicing
No. Parts Name Task Interval Remarks
1 Refresh roller Cleaning 500K Durable. Interval is 1000K sheets.
2 Fixing inlet guide Cleaning 500K
3 Fixing roller separation claw Cleaning 500K Durable. Interval is 1000K sheets.
4 Pressure roller separation claw Cleaning 500K Durable. Interval is 1000K sheets.
■
Action for parts replacement
To prevent the abnormal noise, apply the grease (molykote) onto the inner surface and outer
surface of the bushing.
T-2-78
