Technology > Basic Conguration > Functional Conguration > Basic sequence
Technology > Basic Conguration > Functional Conguration > Basic sequence
Basic Conguration
Functional Conguration
The machine may broadly be divided into the following functional system blocks; document
exposure system block, controller system block, laser exposure system block, image
formation system block, xing system block and pickup/feed system block.
Drum
PickupTransfer
Laser scanner
Reader controller
Main
controller
1/2
DC
controller
Option
board
Exposure lampCCD
HDD
Laser exposure
system
Document exposure system
Controller system
Image formation
system
Fixing
Duplexing
feed
Pickup/feed
system
Flow of signal
Flow of paper
Laser beam
Delivery
Fixing
system
Deck
ITB
F-2-1
■
Basic sequence
●
Sequence at Power-On
• Reader
Reader Motor
Scanning Lamp
HP Sensor
SSTBYSREADY
Backwarding
Forwarding
Optical unit position
HP (Shading position)
Gain correction
Offset correction
Backwarding
Forwarding
Shift shading
Fixing shading
White plate dust
detection control
Shading correction
HP (Shading position)
Main power switch ON
• Printer Unit
WMUP WMUPR PSTBY
Main heater(H2)
Sub heater(H3)
Fixing roller
Target temperature
Pressure roller
External heat
lower roller
External heat
upper roller
Engage
disengage
Fixing roller:
180 degree C
Depending on the fixing roller surface temperature at
the time of the main power ON, execute the following control.
- When the temperature is under 50 degree C. - When the temperature is above 50 degree C.
[1]Voltage Control [1]Paper Interval Control
[2]D-max Control
[3]D-half Control
[4]Developing idoling
[5]Secondary Transfer ATVC Control
[6]Secondary Transfer Out Roller Clearning Control
Power ON
Main heater(H8)
Sub heater(H9)
Main heater(H4)
Sub heater(H5)
Main heater(H6)
Sub heater(H7)
Pressure roller motor (M10)
External heat engage/disnage
motor (M12)
Fixing main motor (M11)
Engage
disengage
Auto adjustment
Fixing
roller:
205
degree C
Fixing roller:210 degree C
Pressure roller:150 degree C
External heat upper/lower
roller:230 degree C
F-2-2
F-2-3
