Canon imagePROGRAF iPF680 Service Guide

imagePROGRAF iPF685/680 Service Guide
imagePROGRAF iPF685/680 Service Guide August 2014
Page 16
K. Field Replacement Parts
Field replacement parts are defined as those parts having a limited life that
will be reached during a customer’s specific printer operation, and should be
replaced as needed. Examples of field replacement parts include, but are not
limited to the linear scale and carriage unit.
A field replacement parts list is provided in Table 21 on page 16, to assist in
the initial parts/supplies planning. A recommended part’s life expectancy is
directly related to usage factors, such as paper size, paper quality,
environment, usage application, and printer maintenance. Therefore,
recommended parts do not have a warranty, and Canon USA cannot
guarantee a minimum life.
Note: All field replacement parts shown in the table below are for reference
purposes only, and are subject to change without notice.
Table 21 – imagePROGRAF iPF685/680 Printer Field Replacement Parts List
1 Part numbers are subject to change without notice.
L. Recommended Spare Parts
Canon USA recommends that the Dealer or Authorized Service Provider keep
the following spare parts in stock for replacement purposes in the event of a
hardware failure.
Note: All recommended spare parts shown in the table below are for
reference purposes only and are subject to change without notice.
Unit
Counter
Name
Replacement
Part
Number
1
Description
Replacement
Timing (A1 Size)
Carriage System
CR1
QM4-8485-000
Carriage Unit
28,000 pages
CR2
QM3-4614-000
Flexible Cable Unit
54,100 pages
CR3
QM4-8485-000
Carriage Unit
30,000 pages
QC3-1880-000
Scale, Linear
CR4
QM4-8485-000
Carriage Unit
50,000 pages
Multi Sensor
CR5
QM3-5831-000
Multi Sensor Unit
30,000 pages
Ink Tube System
SP1
QM3-5952-000
Ink Tube Unit
35,400 pages
Purge System PG1
QM3-5988-010
Purge Unit
50,000 pages
QC3-1437-000
Drain Tube Joint Cl
Non-Ejection
Detection
Hma1 QM3-5956-000
Head Management
Sensor Unit
100,700 pages
CR MOTOR
MT1
QK1-5068-000
Motor, Dc
483,900 pages
Transportation
PL1
QK1-0447-000
Motor, Dc
45,200 pages
Mist Collection Mi1
QM3-5853-000
QM3-5854-000
Mist Fan Duct Unit
Fan Unit
31,398 pages
Cutter System
CT1
QM4-8482-000
Cutter Unit
100,000 pages
Waste Ink
WF2
QM3-5805-000
Waste Ink Box Unit
76,610 pages

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
