Canon imagePROGRAF iPF680 Service Guide

imagePROGRAF iPF685/680 Service Guide
imagePROGRAF iPF685/680 Service Guide August 2014
Page 17
Table 22 - imagePROGRAF iPF685/680 Printer Recommended Spare Parts List
Recommended Spare Parts
Description
Item
Number
1
Quantity
Estimated Life
(A0 Sheets)
Remarks
Carriage Unit
QM4-8485-000
1
28,000 N/A
Purge Unit
QM3-5988-010
1
50,000
N/A
Ink Supply Tank Unit (L） QM4-8465-000
1
N/A
N/A
Ink Supply Tank Unit (R） QM4-8460-000
1
N/A
N/A
Operation Panel Unit QM4-8471-000
1
N/A
N/A
Power Supply Ass’y QK1-5141-000
1
N/A
100V-240V
Scale, Linear QD1-0007-000
1
30,000 N/A
Printhead
3630B003AA 1 N/A
N/A
Main Controller Ass’y
(imagePROGRAF iPF680)
QM7-7294-000 1 N/A N/A
Main Controller Ass’y
(imagePROGRAF iPF685)
QM7-7295-000 1 N/A
N/A
1 Part numbers are subject to change without notice.
M. Periodically Replaced Parts
The imagePROGRAF iPF685/680 printers do not have any periodically
replaced parts.

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
