imagePROGRAF iPF685/680 Service Guide
imagePROGRAF iPF685/680 Service Guide August 2014
Page 3
E. Print Plug-In for Microsoft Office
The plug-in bypasses the printer driver to simplify the printing process.
• Easy printing of large-format documents created in Microsoft Word, Excel,
or PowerPoint
• Appears in the Microsoft application tool bar
• Can be configured to print 8.5" x 11" office documents in poster size
F. Dye/Pigment Reactive Ink Set
The 5-Color LUCIA ink set is ideal for technical applications.
• Improves adhesion to media; provides enhanced scratch and marker
resistance; ensures minimal "bleeding" between colors and text
• Utilizes four highly colorfast dye inks
• Newly formulated magenta ink helps produce a wider color gamut in the
red and orange spectrums, compared to previous models.
• Produces crisp, legible small text when printing on colored backgrounds,
or on uncoated technical papers
G. High Speed Printing
Powering the imagePROGRAF iPF685/680 printer is Canon's L-COA (Large
Format Printer Common Architecture) print controller.
• Drives the print engine to lay down ink with speed and precision
• Process large volumes of data
• Optimizes readability and color accuracy of complex high-color GIS
images, and architectural renderings
H. 320GB Internal Hard Disk Drive (imagePROGRAF iPF685 only)
The imagePROGRAF iPF685 printer’s internal 320GB hard drive
accommodates workgroups that need to print large files or sets of files.
• 32GB dedicated to file processing memory
• Easily reprint saved jobs
• Simplifies printing workflow
• Stores and processes large complex files such as 3D and GIS drawings
• Provides advanced error recovery
• Track file and printing information for up to 500 jobs
I. Large Capacity Ink Tanks
The imagePROGRAF iPF685/680 printer supports ink tank sizes of 130ml
and 300ml, with the latter helping to lower the ink cost per print. Tanks may
be interchanged based on user preference.
J. Sub-Ink Tank System
Canon's unique sub-ink tank system allows users to replace empty ink tanks
on the fly without stopping the printer. This is extremely useful during long
print jobs.

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
