Page 18
N. Maintenance Kit
Canon USA has prepared an imagePROGRAF Maintenance Kit to enhance
the durability of the printer, while reducing operating costs. Reduced printer
downtime can be achieved when the Maintenance Kit is utilized. The printer’s
built-in counters and warning messages inform end-users when the
maintenance kit is required.
Table 23 – imagePROGRAF iPF685/680 Printer Maintenance Kit Parts List
Kit Name
Part
Number
1
Counter Name Part Name
Maintenance Kit
（CR/Mi)
QY6-1535-000
CR1
Carriage Unit
CR3
Carriage Unit, Scale Linear
CR5
Multi Sensor Unit
Mi
Mist Fan Duct Unit
1 Part numbers are subject to change without notice.
O. End-User Periodic Maintenance
In accordance with the user’s manual, the end-user is expected to maintain
the following areas of the printer:
• Printhead cleaning (using the operation panel)
• Replacement of Printheads, Ink Tanks, Maintenance Cartridges, and rail
cleaners
• Cleaning of ink mist and other substances around external covers and
output basket area (drying of surfaces after wiping with a damp cloth)

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
