Canon imagePROGRAF iPF680 Service Guide

imagePROGRAF iPF685/680 Service Guide
imagePROGRAF iPF685/680 Service Guide August 2014
Page 1
I. Product Overview
The Canon U.S.A. Inc. (hereafter referred to as Canon USA) line of 5-color printers
is expanded with the Canon imagePROGRAF iPF685/680 24-inch large format
printers. These printers provide enhancements in both software and hardware
capabilities. Both printers accommodate large capacity ink tanks and include sub-
ink-tank systems, allowing users to replace empty ink tanks on-the-fly, without
having to stop the print job. For increased productivity, the iPF685 printer has a
built-in secure 320GB hard drive allowing for enhanced file processing, personal
mailbox space, and job storage of up to 500 print jobs.
The imagePROGRAF iPF685/680 printers ship with the following capabilities.
• User friendly software solutions:
o Direct Print & Share
o Mobile printing through Apple iPad
o Cloud-based portal
o Accounting Manager
o Print Plugin for Microsoft Office
• The imagePROGRAF iPF685/680 enhanced Media Configuration Tool
• As an Energy Star Partner, Canon USA has determined that the
imagePROGRAF iPF685/680 printers meet the Energy Star guidelines for
energy efficiency

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
