XI. Appendix
Note: All specifications are for reference purposes only and are subject to change
without notice.
A. Specifications
Table 25 – imagePROGRAF iPF685/680 Printer Specifications
Item
Specifications
Type
Bubble jet printer
Media feed system
Roll paper / Cut sheet, (Manual switching)
Media loading
capacity
Roll paper
One (1) roll: Outer diameter: 150mm or less
2 -inch (standard) / 3 -inch (standard)
Manual feed (front)
1 sheet
Delivery method
Face-up delivery
Delivery capacity
Normal position：One (1) sheet
Ejecting position A (Flip loading)/ position B (face-up
loading)
：
Approximately 20 sheets*1
Cutter
Automatic horizontal cut (round blade)
Media width for printing without
borders
Approximately:10"(254mm), 14"(356mm), 17"(432mm),
24"(610mm), B4(257mm), A3(297mm), Banner (300mm),
A2(420mm), A2+(432mm), B2(515mm), A1(594mm)
Maximum
Media size
Roll paper: width
Approximately 609.6mm(24")
Roll paper: length
Approximately 18m (59.6ft )
Cut sheet paper: width
Approximately 609.6mm(24")
Cut sheet paper: length
Approximately 1.6m (5ft 3in )
Print
assurance
area
Roll paper
Margin of leading edge: 20mm, margin of trailing edge: 5mm,
margin of left and right edges: 5mm
Cut sheet paper
Margin of leading edge: 20mm, margin of trailing edge:
23mm, margin of left and right edges: 5mm
Printable area
Roll
paper
With borders
Margin of leading edge: 3mm, margin of trailing edge: 3mm,
margin of left and right edges: 3mm
Borderless
Cut sheet paper
Margin of leading edge: 3mm, margin of trailing edge: 23mm,
margin of left and right edges: 3mm
Paper
thickness
Roll paper
0.07mm - 0.8mm
Cut sheet paper
Detection
adjustment
Dot adjustment
Auto/ manual
Band adjustment
Auto/ manual
Length adjustment
Manual
Print head tilt adjustment
Auto/ manual
Color calibration
No
Print head height shift
Auto/ manual (6 shift
）
Non-ejection detection
function
Yes
Non-ejection complement
function
Yes
Roll paper remaining
control function
Yes

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
