Table 25 - imagePROGRAF iPF685/680 Printer Specifications, continued
Item
Specifications
Self-diagnostic function
LED flashes and lights up on the operation panel,
and displays an error on LCD.
Support Language
Printer language
GARO (Graphic Arts language with Raster
Operations), HP-GL/2, HP RTL
Job control
CPCA
Status response
CPCA, SNMP-MIB (Standard MIB, Canon-MIB)
Memory
32GB(physical memory 256MB)
Hard Disk
320GB (imagePROGRAF iPF685 only)
Interface
USB
Mode
Full Speed(12 Mbit/sec), High Speed (480
Mbit/sec), bulk transfer
Connector
Series B (4-pin)
Ethernet
Standard
IEEE 802.3 10base-T,
802.3u 100base-TX/Auto-Negotiation,
802.3ab 1000base-TX/Auto-Negotiation,
802.3x Full Duplex
IEEE802.3az EEE
Protocol
SNMP(Canon-MIB supported), HTTP,
TCP/IP(IPv4/IPv6)
Expansion slot
No
Print head
Ink ejection method
Bubble jet method
No. of nozzles
MBK: 5,120 nozzles, other colors 2,560 nozzles
Highest Resolution
2400×1200dpi
Ink Tank
Ink color
MBK/BK /C/M/Y
Ink capacity
Packaged with a printer: 90ml (MBK is 130ml),
consumables: 130ml, 300ml
Ink supply method
Tubing method (with sub tank)
Operational Acoustic
Sound pressure level (reference values)
During standby: Approximately, 35 dB (A) or less
During printing: Approximately, 47 dB (A) or less
Acoustic power level:
During printing : Approximately, 6.4Bels or less
Printing condition : normal paper, standard, line
drawing /text mode, Measured based on printing
conditions of ISO7779)
Operational Environment
Temperature: 15 to 30°C, Humidity: 10 to 80%
(No condensation)
Power Supply
AC100V - 240V (50Hz/60Hz)
Power
Consumption
During operation
During operation:140W or less
During standby (power
saving mode)
100 - 120V
220 - 240V
During power off standby
0.5W or less
Package Dimension /
Weight
Main unit for CUSA
(including stand + basket
+ pallet)
Approximately: 1127mm (45") W x 878 mm (34") D
x 1145 mm (45") H, Weight : Approximately 93kg
(205lb)

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
