4.
Removing the Developing Drive Unit
■ Preparation
1. “ Removing the Rear Cover” on page 109
2. “ Removing the Left Rear Cover” on page 109
3. “ Removing the Main Controller PCB” on page 193
4. “ Removing the Fixing Assembly” on page 212
5. “Removing the Inlet Cover” on page 111
6. “ Removing the Low-Voltage Power Supply PCB” on page 195
■ Procedure
1.
4. Parts Replacement and Cleaning
206
