Pickup Feed System
Removing the Paper Delivery Unit
■ Preparation
1. “ Removing the Finisher Rear Cover” on page 119
2. “ Removing the Finisher Left Rear Cover” on page 121
3. “ Removing the Staple Cover” on page 122
4. “ Removing the Staple Unit” on page 225
5. “Removing the Jogger Unit” on page 225
6. “ Removing the Finisher Right Upper Cover” on page 119
7. “ Removing the Staple Inner Cover” on page 123
8. “ Removing the Finisher Right Rear Cover” on page 121
9. “ Removing the Finisher Right Lower Cover” on page 122
10. “Upper Paper Feed Unit” on page 227
11. “ Removing the Rear Cover” on page 109
12. “ Removing the Left Rear Cover” on page 109
13. “Removing the Finisher Fan” on page 226
14. “ Removing the Fixing Assembly” on page 212
15. “ Removing the Front Cover” on page 110
16. “ Removing the Delivery Tray” on page 124
17. “ Removing the Inner Delivery Rear Cover” on page 124
18. “ Removing the Finisher Inner Rear Cover” on page 125
19. “Lower Paper Feed Unit” on page 229
■ Procedure
1.
4. Parts Replacement and Cleaning
214
To Next Page
