Copy Card Reader-F1/Copy
Card Reader Attachment-B5
Points to Note when Installing
• To install this equipment, the Copy Card Reader
Attachment is required.
• Although the figure shows a model without the Finisher,
the same procedure applies to the one with the Finisher.
• Refer to "Table of Options Combination" when installing
this equipment before operation.
Table of Options Combination
IC Card Reader
Attachment-A1
Copy Control In-
terface Kit-A1
Copy Card Reader No No
Yes : Available, No : Unavailable
Installation Outline Drawing
Checking the Contents
< Copy Card Reader-F1>
< Copy Card Reader Attachment-B5>
TP;
M3x6
TP;
M4x12
5x
TP;
M3x12
2x
2x
4x
1x
1x
1x
1x
2x
1x
1x
1x
1x
1x
1x
1x
Binding;
M4x6
2x
Screw,w/washer;
M3x14
9. Installation
601
To Next Page
