Removing the Finisher Motor
■ Preparation
1. “ Removing the Rear Cover” on page 109
2. “ Removing the Finisher Rear Cover” on page 119
3. “Removing the Finisher Fan” on page 226
■ Procedure
1.
Upper Paper Feed Unit
■ Preparation
1. “ Removing the Finisher Rear Cover” on page 119
2. “ Removing the Finisher Left Rear Cover” on page 121
3. “ Removing the Staple Cover” on page 122
4. “ Removing the Staple Unit” on page 225
5. “Removing the Jogger Unit” on page 225
6. “ Removing the Finisher Right Upper Cover” on page 119
7. “ Removing the Staple Inner Cover” on page 123
8. “ Removing the Finisher Right Rear Cover” on page 121
9. “ Removing the Finisher Right Lower Cover” on page 122
4. Parts Replacement and Cleaning
227
To Next Page
