FEEDER (ADF service mode)
DISPLAY (State display mode)
FEEDER (ADF service mode) > DISPLAY (State display mode)
FEEDSIZE 1 Dspl orgnl size detected by DADF/Cpybrd
Detail To display the original size detected by the DADF/Copyboard.
Use Case
When checking the paper size recognized by the device after scanning
Adj/Set/Operate Method
N/A (Display only)
ADJUST (Adjustment mode)
FEEDER (ADF service mode) > ADJUST (Adjustment mode)
DOCST 1 Adj of DADF img lead edge margin: front
Detail To adjust the leading edge margin on the front side at DADF reading.
Execute this item when the output image after DADF installation is displaced.
When clearing the Reader-related RAM data/replacing the SATA Flash PCB, enter the value of
service label.
As the value is incremented by 1, the margin is reduced by 0.1 mm. (The image moves upward.)
Use Case
- When installing DADF
- When clearing the Reader-related RAM data
- When replacing the SATA Flash PCB
Adj/Set/Operate Method
Enter the setting value (switch negative/positive by -/+ key) and press OK key.
Display/Adj/Set Range
-30 to 30
Unit
mm
Default Value
0
Amount of Change per
Unit
0.1
LA-SPEED 1 Fine adj img ratio: DADF,vert scan,front
Detail To make a fine adjustment of the front side image magnification ratio in vertical scanning direction
at DADF reading.
As the value is incremented by 1, the image is reduced by 0.01% in vertical scanning direction.
(The feeding speed increases, and the image is reduced.)
Use Case
- When installing DADF
- When replacing the SATA Flash PCB
- When replacing the clearing the Reader-related RAM data
Adj/Set/Operate Method
Enter the setting value (switch negative/positive by -/+ key) and press OK key.
Display/Adj/Set Range
-200 to 200
Unit
%
Default Value
0
Amount of Change per
Unit
0.01
8. Service Mode
548
