IPFAX Setting
■ IPFAX
● BASIC N
Bit Function Setting range
2 Session control reception timeout (sec.) 0 to 9999 (0*)
20 Reception start delay time (sec.) 0 to 9999 (0*)
21 BYE sending delay time at transmission (x10 msec.) 0 to 9999 (0*)
22 BYE receiving delay time at transmission (x10 msec.) 0 to 9999 (0*)
● NETA NUM
Bit Function Setting range
1 T0 timer(Timer C) for IPFAX(sec.) 0 to 9999 (55*)
● NETC NUM
Bit Function Setting range
1 SW for adjusting the speed at VoIPGW transmission [%] 0 to 9999*
However, the value is fixed in the case of
ECM, and is corrected by adding 5 %.
2 VoIPGW buffer size [byte] 0 to 9999*
However, when the value is 0, it is internally
interpreted as 200.
3 Packet division size [byte] 0 to 9999*
However, when the value is 0, it is internally
interpreted as 66.
4 Number of VoIPGW buffer reset frames at ECM
* At ECM transmission, when frames of the number of this NUM value have
been transmitted, the next frames will be transmitted after the VoIPGW buffer
becomes empty.
0 to 9999*
However, when the value is 0, it is internally
interpreted as 16.
● T.38 Bit Setting
SW01
Bit Function Setting range
1 0
1 German mode is effective during T.38 communication. Effective Invalid *
2 T.38 significant bit of DIS (bit123) is ignored.
(When this SW is effective, the other party's machine is regarded as IPFAX even if DIS
bit123 is 0.)
Ignore Not ignore
3 Transmission ECM = OFF setting Effective Invalid *
4 Reception ECM = OFF setting Effective Invalid *
● T.38 NUM Setting
Bit Function Setting range
1 High-speed flag sending time of ECM mode for IPFAX (x10 msec.). 0 to 9999 (0*)
2 WAIT time from the close of T.38 to the close of SIP: Unit; second
(However, the setting becomes 2 seconds even if the setting is changed to 2
or more. ).
0 to 9999 (1*)
8. Service Mode
574
