Setting Item Description, Instructions
GL2 Set-
tings
Line &
Pen
Manager
Ln wdth correct Corrects by using a correction value that specifies the pen
width.
You can configure Black/gray and Color for each group.
The specified range is -20 to +20.
Proces-
singOp-
tion
Warning Select On to have any GL2-related warnings displayed.
On-the-Fly Selecting On will start printing jobs sooner if you are printing
only HP RTL print jobs and printing would not start until lat-
er. However, images may be incomplete in some cases, so
be sure to check the printing results.
Detect img size Sets the method of deciding the region to output in order to
print efficiently while avoiding missing images.
If Off is selected and the data contains image range infor-
mation, the image range information is followed.
If Off is selected and the data does not contain image range
information, a size with the maximum roll paper width of the
printer for the width and 1.5 times the maximum roll paper
width for the length is used.
If Command priority is selected and the data contains im-
age range information, the image range information is fol-
lowed.
If Command priority is selected and the data does not con-
tain image range information, the detected minimum image
area is used.
If Detected size is selected, the detected minimum image
area is used.
GL2 Set Print Print GL2 settings information.
Interface
Setup
EOP Timer Specify the timeout period before cancellation of print jobs
that cannot be received by the printer.
TCP/IP IPv4 IPv4 Mode Choose whether the printer IP address is configured auto-
matically or a static IP address is entered manually.
Protocol DHCP Specify the protocol used to configure the IP address auto-
matically.
BOOTP
RARP
IPv4
Settings
IP Address Specify the printer network information when using a static
IP address.
Enter the IP address assigned to the printer, as well as the
network subnet mask and default gateway.
The value that was automatically configured is displayed if
you have set IPv4 Mode to Automatic.
Subnet Mask
Default G/W
DNS
Settings
DNS Dync update Specify whether DNS server registration is updated auto-
matically.
Pri. DNS SrvAddr Specify the DNS server address.
Sec. DNS SrvAddr
DNS Host Name Specify the DNS host name.
DNS Domain Name Specify the DNS domain name.
IPv6 IPv6 Support Specify whether to connect via IPv6.
IPv6 StlessAddrs Specify whether a IPv6 stateless address is used.
DHCPv6 Specify whether DHCPv6 settings are used.
DNS
Settings
DNS
Dync
update
Statefull
Addr
Specify whether DNS server registration is updated auto-
matically.
Menu Settings
iPF685
User's Guide
Control Panel Printer Menu
466
