Canon iR4570 Series User Manual

Chapter 8
8-32
8.3.2.2 Stationary Jam at Power-On 0007-2666
iR2270 / iR2870 / iR3570 / iR4570
The machine makes a check to see that there is no paper over the following sensors before it starts initial multiple
rotation at power-on:
T-8-6
8.3.3 Other Jams
8.3.3.1 Door Open Jam 0007-2668
iR2270 / iR2870 / iR3570 / iR4570
A door open jam is identified when the machine detects the opening of the door while it is making copies/prints.
T-8-7
Fixing outlet sensor (PS13)
No. 1 delivery sensor (PS14)
Duplex feed sensor (PS17)
Sensor
Cassette 1 retry sensor (PS10)
Cassette 2 retry sensor (PS11)
Registration sensor (PS9)
Fixing outlet sensor (PS13)
No. 1 delivery sensor (PS14)
Duplex feed sensor (PS17)
Sensor
Front cover open sensor (PS22)
Right cover open sensor (PS18)
Sensor

Canon iR4570 Series Specifications

General

Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Modem Speed	33.6 Kbps
Functions	Print, Copy, Scan, Fax (Optional)
Print Speed	45 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Type	Laser
Warm-up Time	Less than 30 seconds
Memory	256 MB
Paper Sizes	A4, A5, B5, Legal, Letter, Executive
Copy Speed	45 cpm
Multiple Copies	Up to 999 copies
Zoom	25-400%
Scan Speed	45 ipm
Scan Destinations	Email, FTP
Fax Resolution	Up to 400 x 400 dpi
Fax Memory	512 pages
Interface	Ethernet
Fax Transmission Speed	Approx. 3 seconds per page
Operating System Compatibility	Windows, Mac
