2-7
Installing the Printer
2
Installation Site
■ PAPER FEEDER PF-35P
NOTE
The front feet are 7.8 mm high and their top surface is 12 mm square.
The rear feet are 7.8 mm high, the left top surface has a rectangular shape of 21.7 mm x
40 mm, and the right top surface is 31.7 mm x 40 mm and is L-shaped.
(mm)
26.7 294 40.3
26.7
305.8 28.5
62.7282.454.6
61.927661.8
Front Surface
