OPERATOR MANUAL |CAPTAIN 273 4WD 103
General Data
TRACTOR MODEL
CAPTAIN 273 4WD
Front
6.00 x 12
Rear
8.3 x 20
Weight
In running order ;with full tank without ballast with safety frame (Kg)
985
Dimensions
A- Height at safety frame max.(mm)
2025
B- wheelbase (mm)
1550
C- Max.length with front ballast and rods (mm)
2650
D- Ground Clearance (mm)
265
E- Rear track (mm)
830
F- Front track (mm)
920
G- Min.width (mm)
1040
Fig.6-1
Technical
Specification
