OPERATOR MANUAL |CAPTAIN 273 4WD 62
4.28 To adjust the stabilizers:
• Turn clockwise to increase lateral swing.
• Turn anti-clockwise to reduce swing.
NOTE - When an implement is raised to on-road transport position, lateral swing of the three-
point linkage must be reduced.
4.29 Lower links (4)
Lower links with Class 2 fixed ball ends (Fig.4-13).
Adjusting the RH and LH vertical lift rods.
The two vertical lift rods can be adjusted by means of adjuster arms in order to alter the lateral angle of
the implements.
The latter position must be used for implements that require a certain freedom of movement
(cultivators, spaders, harrows, ploughs).
WARNING: ALWAYS use great caution when adjusting or using the three-point linkage.
4.30 Hitching implements
Lower the three-point linkage.
Adjust the lateral stabilizer to let the lower links swing freely.
Reverse the tractor on the implement.
Raise the three-point linkage until the hooks on the lower links fasten on to the ball ends on the
implement crossbar and secure them with safety clips.
