Captain 273 4WD - Fuel Level Gauge; Dashboard

OPERATOR MANUAL |CAPTAIN 273 4WD 45
3.5 Fuel level gauge
When the pointer moves into the amber zone it
shows there are still about 5 liters of fuel in the
tank.
Red - Reserve
Amber – Reserve to 1/4
Green –1/4to full
3.6 Dashboard
1. Park Brake OPC indicator.
2. Working light indicator.
3. Hazard Light Switch.
4. (Fig.3-7a) Combination Switch.
5. (Fig.3-7b) Mobile Charging Socket.
6. Ignition key.
7. (Fig.3.7c) Battery Isolator Switch
(Fig.3-5)
(Fig.3-6)
