OPERATOR MANUAL |CAPTAIN 273 4WD 47
3.6 Seat
The driver’s seat can be adjusted in horizontal and vertical
control (Fig.3-8)
Horizontal adjustment.
1 lift the lever to move the seat forward or backward
2 2 Seat height vertical adjustment Use knob to adjust the
suspension 4 use knob to adjust the height of seat vertically.
3 Seat belt (Fig.3.8)
3.8 Tool box
(1) Tool box contains a kit of tools for the daily maintence. (Fig.3-9)
3.9 Under Hood Muffler
• Under hood muffler with better aesthetics and increased
field of vision with better sound muffing capabilities.
• Heat Insulation & sound muffing sheets under the bonnet
hood for noise reduction
(Fig.3-8 (side view of seat)
