Captain 273 4WD - RPM Meter; Engine Coolant Temperature Gauge

OPERATOR MANUAL |CAPTAIN 273 4WD 44
3.3 RPM meter
The engine rate is displayed by a pointer (1) on
the graduated scale. The pointer should never
reach the 2400 RPM zone which shows excessive
engine speed. (Fig.3.3)
3.4 Engine coolant temperature gauge.
 Green area = normal operating temperature.
Wait for the pointer to reach the green area,
indicating the normal operating temperature.
 Red area = temperature too high.
CAUTION: If the engine temperature is too high,
let the engine idle immediately but do not switch
it off. If the temperature gauge stays in the red,
identify the cause immediately and seek expert
advice if necessary.
(Fig.3-4)
(Fig.3-3)
