OPERATOR MANUAL |CAPTAIN 273 4WD 63
5. Adjust the stabilizers to give the right amount of lateral
swing for the implement.
6. Hitch up and adjust the top link.
4.31 Unhitching implements
1. Lower the implement to the ground.
2. Adjust the stabilizers to give the correct freedom of
movement to the lower links.
3. Remove the safety clips and unhitch the implement's
crossbar from the hooks on the lower links.
The following are important warnings for the operation and
adjustment of implements on the three point linkage.
Use for adjusting the float position use in vertical position if
certain degree of freedom is required for trail type
implements. Use horizontal adjustment for locking the
lower links and for adequate sensing. Also use the float
mode. Fig 4-14 while hitching the implements for ease
in hitching.
WARNING: ALWAYS stop the engine before
attempting to adjust the three-point linkage or
any implement hitched to it.
WARNING: ALWAYS select position control
mode when transporting mounted implements
on the three-point linkage. Lock the implement
into transport position.
WARNING: ALWAYS select position control
mode when hitching or unhitching an
implement to the three-point linkage.
