OPERATOR MANUAL |CAPTAIN 273 4WD 46
Combination Switch for following operations:
A: Left hand direction indicator.
B: Right hand direction indicator
C: Road light switch: turn the knob to operate the Head Light.
D: Push the Centre button for Horn.
Lights off.
Parking Light.
Dipped beams. Pushed down:
driving beams.
High Beam.
Pressed Horn.
Symbol for the Combination Switch
(Fig.3-7a) Combination Switch
((Fig.3-7b) Mobile Charging Socket
(Fig.3-7c) Battery Isolator Switch.
