ANNUNCIATORS
The Model 185 Weight Indicator is equipped with annunciators that are turned on to indicate
that the display is in the mode corresponding to the annunciator label or that the status
indicated by the label is active. This section describes each annunciator.
Symbol Name Description
0
ZERO
This annunciator is turned on to indicate that the weight
displayed is within ± 1/4 division of true zero.
STABLE
The stable annunciator will be on when the weight is
stable to within the limits established during setup.
G
GROSS
This annunciator is turned on to show that gross weight
is displayed. Gross weight will be displayed when no
tare weight is stored.
N
NET
This annunciator is turned on when the displayed
weight is Net weight (Gross weight less Tare weight).
T
TARE
This annunciator is turned on to show that the displayed
weight is the tare weight.
lb
pounds
This annunciator is located to the right of the weight
display and is turned on to show that the displayed
weight unit is pounds.
oz
ounces
This annunciator is located to the right of the weight
display and is turned on to show that the displayed
weight unit is ounces.
kg
kilograms
This annunciator is located to the right of the weight
display and is used to indicate that the displayed unit of
weight measurement is kilograms.
g
grams This annunciator is located to the right of the weight
display and is used to indicate that the displayed unit of
weight measurement is grams.
C
COUNT This annunciator shows that the display is in the Count
mode, and the value displayed is in pieces (the count
quantity) and not weight.
F
FINE SPAN
This annunciator shows that the indicator is in the Fine
Span Adjustment mode of setup.
Battery Status
The battery status indicator will be displayed on the
Model 185B when batteries are installed. The number
of bars indicates the level of charge.
Note that as the battery approaches full discharge, the
outline of the battery will start to flash.
NOTE: When the AC power adapter is connected to the
indicator and is charging the batteries, the charge level
status bars will scroll.
