Carel IR33

27ir33 platform “connections” +030220445 - rel. 2.3 - 27.04.2011
Tab. 7.a
ENGLISH
Connections
Type of connection Cross-sections Maximum current
fi xed screw 16A for cables from 0.5 to 2.5 mm2 12 A
plug-in for screw blocks for cables from 0.5 to 2.5 mm2 12 A
spade with crimped contact for cables from 0.5 to 2.5 mm2 12 A
Wire cross-section for probes and digital inputs 0.5 to 2.5 mm2 (from 20 to 13 AWG)
Wire cross-section for power supply and loads 1.5 to 2.5 mm2 (from 15 to 13 AWG)
The correct sizing of the power and connection cables between the instrument and the loads is the responsibility of the installer.
In the max load and max operating temp. conditions, the cables used must be suitable for operation up to 105°C.
Case plastic dimensions: 111x70.4x60 mm
Assembly DIN rail: using built-in fastening system
drilling template for front panel: dimensions 45x70mm
Display digits: 3 digit LED
display: from -99 to 999
operating status: indicated with graphic icons on the display
Keypad 4 silicone rubber buttons
Infrared receiver available depending on the model
Clock with backup battery available depending on the model
Buzzer available in all models
Clock Error at 25 °C: ± 10 ppm (±5.3 min/year)
Error in the temperature range -10T60 °C: - 50 ppm (-27min/year)
Ageing: < ± 5 ppm (±2.7 min/year)
Discharge time: typically 6 months (8 months maximum)
Recharge time: typically 5 hours (< 8 hours maximum)
Operating conditions
power supply O, L, H: -10T55 °C; <90% RH non-condensing
power supply E, A: -10T50 °C; <90% RH non-condensing
Storage conditions -20T70 °C; <90% RH non-condensing
Front panel index of protection front panel IP40, complete controller IP20
Environmental pollution 2, normal situation
PTI of insulating materials printed circuits 250, plastic and insulating materials 175
Period of stress across the insulating parts long
Category of resistance to fi re category D and category B (UL 94-V0)
Class of protection against voltage surges category II
Type of action and disconnection 1B relay contacts (micro-disconnection)
Construction of the control device electronic control device incorporated
Classifi cation according to protection
against electric shock
class II when appropriately integrated
Device designed to he hand-held or
integrated into equipment designed to be
hand-held
no
Software class and structure class A
Cleaning the front panel of the instrument only use neutral detergents and water
Serial interface for CAREL network Built-in, available in all models, upon request
Interface for repeater display Built-in, available in all models, upon request
Maximum distance between interface
and display
10 m
Programming key Available in all models
Table 6.a
EN13485 certifi cation
The ir33 platform range fi tted with the standard Carel NTC probe is compliant with standard EN 13485 on thermometers for measuring the air temperature in applications on
units for the conservation and sale of refrigerated, frozen and deep-frozen food and ice cream.
Designation of the instrument: EN13485, air, S, A, 1, -50 +90°C. The standard Carel NTC probe is identifi able by the printed laser code on “WP” models, or the code “103AT-11”
on “HP” models, both visible on the sensor part.
