Carel pRack PR100

37
Main screen for dou- ble suction line and double condenser line, separate screens for each line(display only)
--- Hours and minutes … … … --- Date … … … L1-Suction Suction pressure or temperature (line 1) --- … … (**) L1-Condens. Condensing pressure or temperature (line 1) --- … … (**) L1-Superheat Superheat (line 1) --- … … (**) L1-Suct.temp. Suction temperature (line 1) --- … … (**) L1-Disch.temp Discharge temperature (line 1) --- … … (**) --- Unit status (with unit OFF) --- ---
See values on screen for single line
--- Number of compressors on (with unit ON, line 1) --- --- 0…12 --- Compressor activation percentage (with unit ON, line 1) --- % 0…100 --- Number of fans on (with unit ON, line 1) --- --- 0…16 --- Fan activation percentage (with unit ON, line 1) --- % 0…100 L2-Suction Suction pressure or temperature (line 2) --- … … (**) L2-Condens. Condensing pressure or temperature (line 2) --- … … (**) L2-Superheat Superheat (line 2) --- … … (**) L2-Suct.temp. Suction temperature (line 2) --- … … (**) L2-Disch.temp Discharge temperature (line 2) --- … … (**) --- Unit status (with unit OFF) --- ---
See values on screen for single line
--- Number of compressors on (with unit ON, line 2) --- --- 0…12 --- Compressor activation percentage (with unit ON, line 2) --- % 0…100 --- Number of fans on (with unit ON, line 2) --- --- 0…16 --- Fan activation percentage (with unit ON, line 2) --- % 0…100
Main screen for dou- ble suction line and double condenser line, same screen for both lines (display only)
--- Hours and minutes … … … --- Date … … … L1-Suction Suction pressure or temperature (line 1) --- … … (**) L1-Condens. Condensing pressure or temperature (line 1) --- … … (**) L2-Suction Suction pressure or temperature (line 2) --- … … (**) L2-Condens. Condensing pressure or temperature (line 2) --- … … (**) L1-Suct.temp. Suction temperature (line 1) --- … … (**) L1-Superheat Conden- sing
Superheat (line 1) --- … … (**)
L2-Suct.temp. Suction temperature (line 2) --- … … (**) L2-Superheat Superheat (line 2) --- … … (**) L1-Disch.temp Discharge temperature (line 1) --- … … (**) L2-Disch.temp Discharge temperature (line 2) --- … … (**) --- Unit status (with unit OFF) --- ---
See values on screen for single line
--- Compressor activation percentage (with unit ON, line 1) --- % 0…100 --- Compressor activation percentage (with unit ON, line 2) --- % 0…100 --- Fan activation percentage (with unit ON, line 1) --- % 0…100 --- Fan activation percentage (with unit ON, line 2) --- % 0…100
