38
Main screen for
double suction line
and single condenser
line,
(display only)
--- Hours and minutes … … …
Suction: Date … … …
L1 Suction pressure or temperature (line 1) --- … … (**)
L2 Suction pressure or temperature (line 2) --- … … (**)
Condensing Condensing pressure or temperature --- … … (**)
L1-Suct.temp. Suction temperature (line 1) --- … … (**)
L1-Disch.temp Discharge temperature (line 1) --- … … (**)
L1-Superheat Superheat (line 1) --- … … (**)
L2-Suct.temp. Suction temperature (line 2) --- … … (**)
L2-Disch.temp Discharge temperature (line 2) --- … … (**)
L2-Superheat Superheat (line 2) --- … … (**)
--- Unit status (with unit OFF) --- ---
See values on screen for single
line
--- Compressor activation percentage (with unit ON, line 1) --- % 0…100
--- Compressor activation percentage (with unit ON, line 2) --- % 0…100
--- Fan activation percentage (with unit ON, line 1) --- % 0…100
Mask index Display description Description Default UOM Values
A.Unit status
Aa01
(display only)
Pressure Suction pressure (line 1) --- … … (**)
Sat.temp. Saturated suction temperature (line 1) --- … … (**)
Act.setpoint
Eff ective set point for pressure control (with compensation applied, line
1)
…(**) … …(**)
Diff erential Control diff erential for pressure control (line 1) …(**) … …(**)
Aa02
(display only)
Pressure Suction pressure (line 1) --- … …(**)
Sat.temp. Saturated suction temperature (line 1) --- … …(**)
Act.setpoint Eff ective set point for temperature control (with compensation applied, line 1) …(**) … …(**)
Diff erential Control diff erential for temperature control (line 1) …(**) … …(**)
Aa03
(display only)
Actual/req. Capacity delivered/capacity required for suction line (line 1) --- % 0/0 …100/100
Reg.status
Control status (according to the type of control set, line 1) --- ---
Stop Increas
Decrease
Standby
Operating
Timings
Allarms
Reg.type Compressor control type (line 1) Neutral zone ---
Proportional band
Neutral zone
Setpoint Eff ective suction pressure set point (with compensation applied, line 1) …(**) … …(**)
Aa04
(display only)
C01, C02, …C12 Time remaining to next compressor start (line 1) --- s 0…32000
C01
Capacity delivered by compressor 1 on line 1 (a ''!'' to the right of the
value means that some form of compressor capacity override is active,
e.g. times, alarms, start-up procedure)
--- % 0…100
… … ………
C12 Capacity delivered by compressor 12 (line 1) --- % 0…100
Aa05
(display only)
Temperature Suction temperature (line 1) --- … …(**)
Superheat Superheat (line 1) --- … …(**)
