39
Mask index Display description Description Default UOM Values
Aa11
(display only)
Disch.1 Discharge temperature, compressor 1 (line 1) --- … …(**)
…… ………
Disch.6 Discharge temperature, compressor 6 (line 1) --- … …(**)
Aa13
(display only)
Liq.inj.1: DO
Number of digital output associated and status of liquid injection/
economizer (*) compressor 1 (line 1)
--- … 0…29 ON / OFF
…… ………
Liq.inj.6: DO
Number of digital output associated and status of liquid injection/
economizer (*) compressor 6 (line 1)
--- … 0…29 ON / OFF
Aa15
(display only)
Discharge temperature Digital Scroll
TM
compressor discharge temperature (line 1) --- … …(**)
Cap.reduction Digital Scroll
TM
compressor capacity reduction in progress (line 1) NO / YES
Oil sump temp. Digital Scroll
TM
compressor oil sump temperature (line 1) --- … …(**)
Oil status Digital Scroll
TM
compressor oil dilution status (line 1) Ok / Diluite
Aa16
(display only)
Status Digital Scroll
TM
compressor operating status (line 1) --- ---
Off
Start up
On
Alarm
Off by time
On by time
Mod. manual
In pump down
Countdown Digital Scroll
TM
compressor time count (line 1) --- s 0…999
Compr. Digital Scroll
TM
compressor status (line 1) --- --- OFF / ON
Valve Digital Scroll
TM
valve status(line 1) --- --- OFF / ON
Requested cap. Digital Scroll
TM
compressor capacity required (line 1) --- % 0…100
Current capac. Digital Scroll
TM
compressor eff ective capacity (line 1) --- % 0…100
Aa20
(display only)
Pressure Condensing pressure (line 1) --- … … (**)
Sat.temp. Saturated condensing temperature (line 1) --- … … (**)
Act.setpoint Eff ective set point for pressure control (with compens. applied, line 1) … (**) … … (**)
Diff erential Control diff erential for pressure control (line 1) … (**) … … (**)
Aa21
(display only)
Pressure Condensing pressure (line 1) --- … … (**)
Sat.temp. Saturated condensing temperature (line 1) --- … … (**)
Act.setpoint Eff ective set point for temperature control (with compe. applied, line 1) … (**) … … (**)
Diff erential Control diff erential for temperature control (line 1) … (**) … … (**)
Aa22
(display only)
Actual/req. Capacity delivered/capacity required for condenser line (line 1) --- % 0/0 …100/100
Status Control status (according to the type of control set, line 1) --- ---
Stop
Increase
Decrease
Stand-by
Operating
Timings
Alarms
Reg.type Condenser control type (line 1) Neutral zone ---
Proportional band
Neutral zone
Setpoint Condenser control eff ective set point (with compens. applied, line 1) … (**) … …(**)
Aa23 (display only)
F1
Power output of fan 1 on line 1 (a ''!'' to the right of the value means that
some form of power override is active)
--- % 0…100
… … ………
F8
Power output of fan 8 on line 1 (a ''!'' to the right of the value means that
some form of power override is active)
--- % 0…100
