Carel pRack PR100

40
Mask index Display description Description Default UOM Values
Aa24 (display only)
F9
Power output of fan 9 on line 1 (a ''!'' to the right of the value means that some form of power override is active)
--- % 0…100
… … ……… F16
Power output of fan 16 on line 1 (a ''!'' to the right of the value means that some form of power override is active)
--- % 0…100
Aa25 (display only)
Discharge temperature Discharge temperature (line 1) --- … …(**) External temperature Outside temperature (line 1) --- … …(**)
Aa31 (display only)
Pressure Suction pressure (line 2) --- … … (**) Sat.temp. Saturated suction temperature (line 2) --- … … (**) Act.setpoint
Eff ective set point for pressure control (with compensation applied, line 2)
…(**) … …(**)
Diff erential Control diff erential for pressure control (line 2) …(**) … …(**)
Aa32 (display only)
Pressure Suction pressure (line 2) --- … …(**) Sat.temp. Saturated suction temperature (line 2) --- … …(**) Act.setpoint
Eff ective set point for temperature control (with compensation applied, line 2)
…(**) … …(**)
Diff erential Control diff erential for temperature control (line 2) …(**) … …(**)
Aa33 (display only)
Actual/req. Capacity delivered/capacity required for suction line (line 2) --- % 0/0 …100/100 Status Control status (according to the type of control set, line 2) --- ---
Stop Increas Decrease Standby
Operating Timings Alarms
Reg.type Compressor control type (line 2) Neutral zone ---
Proportional band Neutral zone
Setpoint Eff ective suction pressure set point (with compensation applied, line 2) …(**) … …(**)
Aa34 (display only)
C01, C02, …C12 Time remaining to next compressor start (line 2) --- s 0…32000 C01
Capacity delivered by compressor 1 on line 2 (a ''!'' to the right of the value means that some form of compressor capacity override is active, e.g. times, alarms, start-up procedure)
--- % 0…100
… … ……… C12 Capacity delivered by compressor 12 (line 2) --- % 0…100
Aa05 (display only)
Temperature Suction temperature (line 2) --- … …(**) Superheat Superheat (line 2) --- … …(**)
Aa41 (display only)
Disch.1 Discharge temperature, compressor 1 (line 2) --- … …(**) … … ……… Disch.6 Discharge temperature, compressor 6 (line 2) --- … …(**)
Aa43 (display only)
Liq.inj.1: DO N.ro of digital output associated and status liquid injection com.1 (line 2) --- … 0…29 ON / OFF … … ……… Liq.inj.6: DO
Number of digital output associated and status liquid injection compr. 6 (line 2)
--- … 0…29 ON / OFF
Aa45 (display only)
Discharge temperature Digital Scroll
TM
compressor discharge temperature (line 2) --- … …(**)
Cap.reduction Digital Scroll
TM
compressor capacity reduction in progress (line 2) NO / SI
Oil sump temp. Digital Scroll
TM
compressor oil sump temperature (line 2) --- … …(**)
Oil status Digital Scroll
TM
compressor oil dilution status (line 2) Ok / Dilute
