41
Mask index Display description Description Default UOM Values
Aa46
(display only)
Status Digital Scroll
TM
compressor operating status (line 2) --- ---
Off
Start up
On
Alarm
Off da tempo
On da tempo
Mod.manuale
In pump down
Countdown Digital Scroll
TM
compressor time count (line 2) --- s 0…999
Compr. Digital Scroll
TM
compressor status (line 2) --- --- OFF / ON
Valve Digital Scroll
TM
valve status(line 2) --- --- OFF / ON
Requested cap. Digital Scroll
TM
compressor capacity required (line 2) --- % 0…100
Current capac. Digital Scroll
TM
compressor eff ective capacity (line 2) --- % 0…100
Aa50 (display only)
Pressure Condensing pressure (line 2) --- … … (**)
Sat.temp. Saturated condensing temperature (line 2) --- … … (**)
Act.setpoint
Eff ective set point for pressure control (with compensation applied, line
2)
…(**) … …(**)
Diff erential Control diff erential for pressure control (line 2) …(**) … …(**)
Aa51 (display only)
Pressure Condensing pressure (line 2) --- … …(**)
Sat.temp. Saturated condensing temperature (line 2) --- … …(**)
Act.setpoint
Eff ective set point for temperature control (with compensation applied,
line 2)
…(**) … …(**)
Diff erential Control diff erential for temperature control (line 2) …(**) … …(**)
Aa52 (display only)
Actual/req. Capacity delivered/capacity required for condenser line (line 2) --- % 0/0 …100/100
Reg.status Control status (according to the type of control set, line 2) --- ---
Stop Increas
Decrease
Standby
Operating
Timings
Alarms
Reg.type Condenser control type (line 2) Neutral zone ---
Proportional band
Neutral zone
Setpoint Condenser control eff ective set point (with compensat. applied, line 2) …(**) … …(**)
Aa53 (display only)
F1
Power output of fan 1 on line 2 (a ''!'' to the right of the value means that
some form of power override is active)
--- % 0…100
… … ………
F8
Power output of fan 8 on line 2 (a ''!'' to the right of the value means that
some form of power override is active)
--- % 0…100
Aa54 (display only)
F9
Power output of fan 9 on line 2 (a ''!'' to the right of the value means that
some form of power override is active)
--- % 0…100
… … ………
F16
Power output of fan 16 on line 2 (a ''!'' to the right of the value means
that some form of power override is active)
--- % 0…100
Aa55 (display only)
Discharge temperature Discharge temperature (line 2) --- … …(**)
External temperature Outside temperature (line 2) --- … …(**)
