Carl Valentin MICRA - Parts of Printer

Manual
8
Parts of printer
1 Cover open button 10
Printhead pressure
adjusting screw (left/right)
19 Fan-fold label guiding
2 Top cover 11 Ready LED 20 Power switch
3 Label roll core 12 Status LED 21 Power socket
4 Ribbon rewind wheel 13 Feed key 22 USB interface
5 Print mechanism 14 Print line adjusting gear 23 Parallel interface
6
Ribbon rewind shaft +
empty ribbon take up core
15 Ribbon supply shaft 24 Serial interface
7 Locking tenon (left/right) 16 Label guiding 25 Ethernet socket (optional)
8 Front cover 17 Label photocell
9 CPU cover 18 Platen roller
