Manual
9
LOADING OF MATERIAL
Loading of labels in standard mode
Open the top cover by pressing the cover open
button on both sides.
Place the label roll onto the label roll core.
Loosen and lift the upper print mechanism by
pressing the locking tenons.
Note: Check the position of label photocell.
Normally the photocell must be placed rightmost.
Feed the label through the two label guides to the
tear-off bar.
Align the label guides to the label edge.
Close the upper print mechanism from the top to
finish label installation.
