OPTION DISPENSER
Installation of dispenser unit
Remove mains plug from shockproof socket in order to separate printer completely from
power line, otherwise there is a risk to life and limb from the live wires inside the open
printer.
Open the top cover by
pressing the cover open
buttons on both sides.
Push the front cover piece
button inward to open.
Lift/take off the front cover
piece according to
direction shown.
Plug in the connector
according to photo shown.
(3 pin onto converting
board).
The label used in
dispensing mode should
be at least 30 mm in
height
