6.4. Fuse Specification (UL Model Recommended)
Model Manufacture Type Rating
RVLFA110040A Bussmann 20CT 690V 20A
RVLFA110075A Bussmann 25ET 690V 25A
RVLFA120040FA Bussmann 10CT/16CT 690V 10A/690V 16A
RVLFA120075FA Bussmann 16CT/20CT 690V 16A/690V 20A
RVLFB120150FA Bussmann 30FE 690V 30A
RVLFB120220FA Bussmann 50FE 690V 50A
RVLFA320075A Bussmann 10CT 690V 10A
RVLFB320150A Bussmann 16CT 690V 16A
RVLFB320220A Bussmann 20CT 690V 20A
RVLFB340075FA Bussmann 10CT 690V 10A
RVLFB340150FA Bussmann 16CT 690V 16A
RVLFB340220FA Bussmann 20CT 690V 20A
RVLFC340370FA Bussmann 25ET 690V 25A
RVLFC340550FA Bussmann 40FE 690V 40A
RVLFD340750FA Bussmann 50ET 690V 50A
RVLFD3401100FA Bussmann 63ET 690V 63A
6.5. Braking Resistor. 400V range
Model
Braking detection
module
(HP) (kW)
Braking resistor
ED (%)
Braking
torque
(%)
Model
Parallel
Number
(W) (Ω)
Parallel
Number
RVLFA320075A - - 5 3.5 390 40 - 10 117
RVLFB320150A - - 7.5 5.5 600 25 - 10 123
RVLFB320220A - - 10 7.5 780 20 - 10 117
RVLFB340075FA 1 0.75 60 750 8 123
RVLFB340150FA 2 1.5 150 400 10 117
RVLFB340220FA 3 2.2 200 250 8 123
RVLFC340370FA 5 3.5 400 150 10 123
RVLFC340550FA 7.5 5.5 600 100 10 123
RVLFD340750FA 10 7.5 750 80 10 117
RVLFD3401100FA 15 11 1600 50 10 123
