3.1. Initial Power Up
3.2. PROFIBUS-DP Address
3.3. RV-PDP Cyclical Data Exchange
3.3.1. PPO configuration
Before you power on the RV-PDP module, verify that it is properly connected to the power
supply, to the bus connector and to the base unit. If the RV-PDP unit is factory set, the station
address of the PROFIBUS-DP station must be set.
Every PROFIBUS-DP station requires a unique address in the PROFIBUS-DP structure. User
can use the integrated 8bits DIP switch on the RV-PDP to set address. The SW1-1 is the
lowest bit, and the SW1-7 is highest bit, the SW1-8 is not used.
RV-PDP is controlled via cyclical PROFIBUS-DP channel.
This channel can be used to access the parameters of RVLF series diver.
The structure of useful data for the cyclical channel is defined in the PROFIDrive Profile
version2.0. Please refer to the Parameter Process data Object (PPO).
NOTE: Setting address changes via DIP switch will not be effective immediately.
This will be effective after RV-PDP module power re-boot.
Valid PROFIBUS Address range is 1~125
3. Communication
SW_7 SW-6 SW-5 SW-4 SW-3 SW-2 SW-1 Address
OFF OFF OFF OFF OFF OFF OFF 0
OFF OFF OFF OFF OFF OFF ON 1
OFF OFF OFF OFF OFF ON OFF 2
OFF OFF OFF OFF OFF ON ON 3
OFF OFF OFF OFF ON OFF OFF 4
ON ON ON ON ON OFF ON 125
PKW PZD
PKE IND PWE
PZD1
STW
ZSW
PZD2
HSW
HIW
PZD3 PZD4 PZD5 PZD6 PZD7 PZD8 PZD9
PZD10
1st
word
2nd
word
3rd
word
4th
word
1st
word
2nd
word
3rd
word
4th
word
5th
word
6th
word
7th
word
8th
word
9th
word
10th
word
PKW
PKW
PKW
PKW
PKW
