Annex B: RVLF MODBUS address allocation
Register
Code
Function
Block
Function
Block
Function
Block
Register
Code
Function
Block
Register
Code
Function
Block
Register
Code
Function
Block
Group 00 Group01 Group 02 Group 03 Group 04
0000H 00-00 0100H 01-00 0200H 02-00 0300H 03-00 0400H 04-00
0001H 00-01 0101H 01-01 0201H 02-01 0301H 03-01 0401H 04-01
0002H 00-02 0102H 01-02 0202H 02-02 0302H 03-02 0402H 04-02
0003H 00-03 0103H 01-03 0203H 02-03 0303H 03-03 0403H 04-03
0004H 00-04 0104H 01-04 0304H 03-04 0404H 04-04
0005H 00-05 0105H 01-05 0305H 03-05 0405H 04-05
0006H 00-06 0106H 01-06 0306H 03-06 0406H 04-06
0007H 00-07 0107H 01-07 0307H 03-07 0407H 04-07
0008H 00-08 0108H 01-08 0308H 03-08 0408H 04-08
0009H 00-09 0109H 01-09 0309H 03-09 0409H 04-09
000AH 00-10 010AH 01-10 030AH 03-10 040AH 04-10
000BH 00-11 010BH 01-11 030BH 03-11 040BH 04-11
000CH 00-12 030CH 03-12 040CH
04-12
000DH 00-13 030DH 03-13
000EH 00-14 030EH 03-14
000FH 00-15 030FH 03-15
0010H 00-16 0310H 03-16
0011H 00-17 0311H 03-17
0012H 00-18 0312H 03-18
0013H 00-19 0313H 03-19
0014H 00-20
Group 05 Group 05 Group 06 Group 06 Group 07
0500H 05-00 051AH 05-26 0600H 06-00 061AH 06-26 0700H 07-00
0501H 05-01 051BH 05-27 0601H 06-01 061BH 06-27 0701H 07-01
0502H 05-02 051CH 05-28 0602H 06-02 061CH 06-28 0702H 07-02
0503H 05-03 051DH 05-29 0603H 06-03 061DH 06-29 0703H 07-03
0504H 05-04 051EH 05-30 0604H 06-04 061EH 06-30 0704H 07-04
0505H 05-05 051FH 05-31 0605H 06-05 061FH 06-31 0705H 07-05
0506H 05-06 0520H 05-32 0606H 06-06 0620H 06-32 0706H 07-06
0507H 05-07 051EH 05-30 0607H 06-07 0621H 06-33 0707H 07-07
0508H 05-08 051FH 05-31 0608H 06-08 0622H 06-34 0708H 07-08
0509H 05-09 0520H 05-32 0609H 06-09 0623H 06-35
0709H 07-09
050AH 05-10 060AH 06-10 0624H 06-36
050BH 05-11 060BH 06-11
050CH 05-12 060CH 06-12
050DH 05-13 060DH 06-13
050EH 05-14 060EH 06-14
050FH 05-15 060FH 06-15
0510H 05-16 0610H 06-16
0511H 05-17 0611H 06-17
0512H 05-18 0612H 06-18
0513H 05-19 0613H 06-19
0514H 05-20 0614H 06-20
0515H 05-21 0615H 06-21
0516H 05-22 0616H 06-22
0517H 05-23 0617H 06-23
0518H 05-24 0618H 06-24
0519H 05-25 0619H 06-25
Note: Parameter register No.: "GG means Group number, "nn" means parameter number
For example: the address of Pr 08-03 is 803H. The address of Pr 10-11 is 0A0BH.
