Motor Controllers AC Variable Frequency Drives Type VariFlex
3
RVLF
Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 13/12/2017 219
3.3.2. Extended configuration
3.3.3. Default settings of PZD structure
In addition to the PPO types, cyclical data can also be configured to EXT CONF1 or EXT
CONF2 (shown as the table below). These two extended configuration both have four process
data words.
RV-PDP must receive the user parameters from master that configured via GSD file. The default
settings of PZD structure are as follows:
STW1: Control Word, mapping to MODBUS address 0x2501 of RVLF series drive.
HSW: Main set point, mapping to MODBUS address 0x2502 of RVLF series drive.
ZSW1: Drives status, mapping to MODBUS address 0x2520 of RVLF series drive.
HIW: Main actual value, mapping to MODBUS address 0x2524 of RVLF series diver.
PROFIBUS-DP master RVLF series drive
PZD3: Not used.
PZD4: Not used.
RVLF series drive PROFIBUS-DP master
RVLF output status, mapping to MODBUS address 0x2520~0x252D of RVLF series drive. The
default settings of PZD3/PZD4 as follows:
PZD3: Default Multi-function terminal on/off status, mapping to MODBUS address 0x2522 of
RVLF series drive.
PZD4: Default output current, mapping to MODBUS address 0x2527 of RVLF series drive.
NOTE: RV-PDP supports PPO1 and PPO3 structure only.
PKW PZD
PKE IND PWE
PZD1
STW
ZSW
PZD2
HSW
HIW
PZD3 PZD4 PZD5 PZD6 PZD7 PZD8 PZD9
PZD10
1st
word
2nd
word
3rd
word
4th
word
1st
word
2nd
word
3rd
word
4th
word
5th
word
6th
word
7th
word
8th
word
9th
word
10th
word
EXT CONF 1
EXT CONF 2
PKW: Parameter ID/value STW: Control word
PZD: Process data ZSW: Status word
PKE: Parameter ID HSW: Main set point
IND: Sub-index HIW: Main actual value
PWE: Parameter value
