5.4. Routine and Periodic Inspection
To ensure stable and safe operations, check and maintain the inverter at regular intervals.
Use the checklist below to carry out inspection.
Disconnect power after approximately 5 minutes to make sure no voltage is present on the
output terminals before any inspection or maintenance.
Items Details
Checking period
Methods Criteria Remedies
Daily 1Year
Environment & Ground connection
Ambient
conditions at the
installation
Conrm the
temperature and
humidity at the
machine
•
Measure with
thermometer and
hygrometer
Temperature:
-10~+40°C
(14~+120°F)
Humidity: below
95%RH
Improve the
ambient or
relocate the drive
to a better area.
Installation
grounding
Is the grounding
resistance
correct?
•
Measure the
resistance with a
multi-tester
200Vclass: below
100Ω
Improve the
grounding if
needed.
Terminals & Wiring
Connection
terminals
Any loose parts
or terminals?
•
Visual check.
Check with a
screwdriver
Correct
installation
requirement
Secure terminals
and remove rust
Any damage to
the base ?
•
Any corroded
Terminals?
•
Wiring
Any broken
wires?
•
Visual check
Correct wiring
requirement
Rectify as
necessary
Any damage
to the wire
insulation?
•
Voltage
Input power
voltage
Is the voltage of
the main circuit
correct?
•
Measure the
voltage with a
multi-tester
Voltage must
conform with the
spec.
Improve input
voltage if
necessary.
Circuit boards and components
Printed circuit
board
Any
contamination
or damage to
printed circuit
board?
•
Visual check
Correct
component
condition
Clean or replace
the circuit board
Power
component
Any dust or
debris
•
Clean
components
Check resistance
between
terminals
•
Measure with a
multi-tester
No short circuit
or broken circuit
in three phase
output
Consult with the
supplier
Cooling System
Cooling fan
Unusual vibration
and noise?
•
Visual and sound
check
Correct cooling
Consult with the
supplier
Excessive dust
or debris
•
Visual check
Clean the fan
Heat sink
Excessive dust
or debris
•
Clean up debris
or dust
Ventilation Path
Is the ventilation
path blocked?
• Clear the path
