4. Inverter Control
4.1 Command Data (Readable and writable)
Register No. Bit Content
2500H Reserved
2501H
Operation Signal
0
Operation Command
1: Run
0: Stop
1
Reverse Command
1: Reverse
0: Forward
2
Abnormal
1: EFO
3
Fault Reset
1: Reset
4
Jog Forward Command
1: Jog Forward
5
Jog Reverse Command
1: Jog Reverse
6
Multi-function CommandS1
1: “ON”
0: “OFF”
7
Multi-function CommandS2
1: “ON”
0: “OFF”
8
Multi-function CommandS3
1: “ON”
0: “OFF”
9
Multi-function CommandS4
1: “ON”
0: “OFF”
A
Multi-function CommandS5
1: “ON”
0: “OFF”
B Reserved
C
Relay R1
1: “ON”
0: “OFF”
D Reserved
E~F Reserved
2502H Frequency Command
2503~251FH Reserved
Note: Write in zero for not used BIT, do not write in data for the reserved register.
