Group 00 The basic parameters group
No. Description Range
Factory
setting
Unit Note
00-00 Motor rotation
0: V/F model
1: SLV model
0 -
00-01 Motor rotation
0: Forward
1: Reverse
0 - *1
00-02
Main run
source selection
0: Keypad
1 -1: External Run/Stop control
2: Comm unication
00-03
Alternative run
source selection
0: Keypad
0 -1: External Run/Stop control
2: Communication
00-04
Operation modes for
external terminals
0: Forward/Stop-Reverse/Stop
0 -1: Run/Stop-Reverse/Forward
2: 3-Wire control mode-run/stop
00-05
Main frequency
source selection
0: Keypad
2 -
1: Potentiometer on keypad
2: External AVI analog signal Input
3: External ACI analog signal input
4: External Up/Down frequency control
5: Communication setting frequency
6: PID output frequency
00-06
Alternative frequency
source selection
0: Keypad
0 -
1: Potentiometer on keypad
2: External AVI analog signal input
3: External ACI analog signal input
4: External Up/Down frequency control
5: Communication setting frequency
6: PID output frequency.
00-07
Main and alternative
Frequency command modes
0: Main or alternative frequency
1: Main frequency + alternative fre-
quency
0 -
00-08
Communication
frequency command
0.00~599.00 Hz *4
00-09
Frequency command Save mod
(communication mode)
0: Save the frequency before power
down
1: Save the communication frequency
0 -
00-10
Initial frequency
selection (keypad mode)
0: By current frequency command
0 -1: By 0 frequency command
2: By 00-11
00-11 Initial Frequency Setpoint 0.00~599.00 50.00/60.00 Hz
00-12 Frequency upper limit 0.01~599.00 50.00/60.00 Hz
00-13 Frequency lower limit 0.00~599.99 0.00 Hz *1
00-14 Acceleration time 1 0.1~3600.0 10.0 s *1
00-15 Deceleration time 1 0.1~3600.0 10.0 s *1
00-16 Acceleration time 2 0.1~3600.0 10.0 s *1
00-17 Deceleration time 2 0.1~3600.0 10.0 s *1
00-18 Jog frequency 1.00~25.00 2.00 Hz *1
00-19 Jog acceleration time 0.1~25.5 0.5 s *1
00-20 Jog deceleration time 0.1~25.5 0.5 s
